Extending Range

Are there any tricks or techniques you could use to extend the coverage range ?

With home-working now an imperative, many people are installing garden offices, and this is where they have their work PC's, technology, and which really needs protection. Unfortunately,  I just can't get my Simplisafe system to extend to my garden office literally 40 feet from my home. For that reason, I cannot recommend it.

As most people would have wifi in their garden office, it would seem a relatively simple option to buy a second controller which could link to the main controller over wifi - snd be a nice little revenue earner for Simplisafe.   As this isn't an option currently, does anyone have any tricks or techniques I can use to extend my range ?

Thanks


James

Official Response

Community Admin

 •

5.2K Messages

 •

80 Points

4 years ago

Hi!

The sensors do have a range of about 800ft in open air, so they might be able to reach a lot further than you're thinking. Usually, if you're covering an outbuilding, we would suggest that to move your Base Station to the same side of the house as that other building.

The main thing to be aware of is that physical interference does have a major impact on the signal. So if your house has brick or concrete walls, or if your garden office is built out of a metal shed, that can be the limiting factor.

(edited)

1.3K Messages

4 years ago

I have two SS2 systems, each has at least one door sensor on detached garage. One is approximately 70ft from base to sensor, the 2nd is probably closer to 200ft from base to sensor. Been this way for months. Haven't yet received any sort of sensor not responding message. Both houses have steel siding on them.

3 Messages

3 years ago

I can't seem to get my barn sensors to stay connected. They are only 45ft away from the base station. The only interference is the metal walls. Wish I could run an Ethernet cable out to a hot spot or something and keep it connected

Captain

 •

5.7K Messages

 •

130 Points

3 years ago

@chad01 there are several customer hacks that show how to install an antennae to bet further range. You have to be handy and, of course, voids your warranty, but entry sensors at under 15 bucks makes these home remedies sometimes worth trying. Use a google site search. Also check youtube.

Here is one link to get you started. Good luck.

https://www.instructables.com/Boosting-Signal-Range-of-SimpliSafe-DoorWindow-Sen/

3 Messages

@captain11

I did this hack for a door entry sensor for the new system by soldering a 1 meter length of wire to the internal antenna.  It works!  Distance is 40+ ft through 3 walls from the base station.

Captain

 •

5.7K Messages

 •

130 Points

@jackl89 As This is exactly what I was referring to, customers who are much more handy than the likes of me adapting existing products! (Sorry, have to say the obvious that this nukes your warranty.)  Simplisafe, looks like a great opportunity for a whole new line of products that are "destined to leverage SS engineering and design to provide "maximum" performance at a minimal price difference"....okay, so I am not good at marketing either but I think you get the idea.  Nicely done jackl89!

3 Messages

@captain11 No warranty is a small price to pay for getting the $15 sensor to work reliably - no dreaded "sensor not responding" message.  The reported operating frequency of 300 MHz means that a 1 meter wire is full wave resonant, providing much more gain than the internal antenna stub.  It's an easy 5 minute fix, just be careful to note the placement of parts (and don't lose them, especially the reset button!), and drill and solder carefully.  The aesthetic drawback is the extended wire, but since I use this in the garage, I don't need to conceal it.

2 Messages

Was going to try this myself at some point anyway, and after coming across this thread yesterday, I decided to give it a shot for my outdoor shop sensor that has constantly failed since upgrading to G3. G1 never failed, BTW.

22 gauge stranded and insulated (smallest and all I had handy) wire, 1 meter long. Whole process took < 15 minutes. The shop is only about 200' from the base, but it's a metal (aluminum) pole building and it just hasn't worked since I put the new sensors in. Long story short(er), I got a message on my phone almost instantly after I soldered the wire, that my sensor had been restored. On the BENCH in the SHOP no less. Works like a champ now.

I may do this mod and start selling them for a small fee if SimpliSafe doesn't get their act together and offer a sensor with a longer antenna for extended range. Outstanding mod.

(edited)

1 Message

@WilsonFlyer came here for this answer....my man!....oh and you're a go for launch with that small business idea my friend lol

1 Message

2 years ago

I have recently purchased a water sensor for my water heater. I live in a ranch type home and my base station is on the main floor in the middle of the house. My water sensor is under my water heater which is in the basement and the sensor is therefore on the concrete floor. The actual distance can't be more than 30-35ft but it's through several walls (all drywall) and two 3/4" hardwood floors (1 1/2" - don't ask). I keep getting the "sensor not responding" message. I guess I'll try the wire idea mentioned above to try and extend the range of the sensor. Thanks for the suggestion!

Captain

 •

5.7K Messages

 •

130 Points

@bclonchii​ My base is upstairs in a guest bedroom and the water sensor (1 of 4) is next  to the water heater and connects fine through 3 levels (basement, 1st, 2nd floor) without issue. Suggest you try moving the water sensor first and if still no luck try moving the base too.

Please post your outcome here after your attempt(s) if you get a chance.

2 Messages

1 year ago

Thanks for this I've just soldered a wire to the antenna and the door sensor is now working at range.

(edited)

39 Messages

1 year ago

You actually want the antenna wire to be exactly 1/4 wavelength long.  The frequency used is exactly 433.92 MHz.

2 Messages

1 year ago

You are exactly right, Jim. For best results and without getting into all of the technical variations and options, one meter will produce the most optimal results from my research. I have been thinking about slightly over powering mine also as another option to boost signal strength as mine seems prone to time of year also (humidity, temp. foliage, etc.), but I haven't gone down that rabbit hole. Yet. LOL

2 Messages

1 year ago

I'll shorten mine then, thanks!

39 Messages

1 year ago

You want exactly 6.80 inches in length, including the length of the internal wire is you are leaving that in place and connecting to the far end of that wire.

16 Messages

1 year ago

There's a big difference (relatively speaking) between one metre (39.3701") and 6.8" (0.17272 metre).

1 Message

1 year ago

The wavelength over air of a 433MHz is approximately 69 cm (27.2"), so an antennae of that size (which is slightly less than a meter) should give the best gain.  1/2 or 1/4 lengths should also provide a significant improvement however.  The 6.8" (17.3cm) number given is 1/4 length antennae.

4 Messages

1 year ago

Enough Already! Simplisafe - release a plug in repeater with 24-hour battery backup -  like Ring! Come on already! I cannot locate the base station where all devices are in range. This is stupid... 800 feet "open air" range is a useless metric. People walls, metal ductwork, stone, granite, solid poured concrete foundations, etc. You need to develop a solution now for the realities many homes, or forget, I am gone, and I'm sure many others have left or are considering.

And your latest firmware update WIPED OUT my continuation. EVERY DEVICE was removed. As ridiculous that is on its own, what if I were on vacation and the update just "happened"? (I didn't initiate the update)

The reliability is Simplisafe is well below the threshold one must maintain for a SECURITY system.

(edited)

1 Message

I have to agree with this. The Simplisafe response to move your base station is almost as ridiculous as the idea that to get whole home coverage I need to solder wire onto my sensors.

If I don’t see a solution to the range issue within the next 90 days from Simplisafe I will be cancelling my subscription and sending my whole system to my circular, bottomless, forever storage bin.

1 Message

7 months ago

This is a great hack!

New generation door sensor 200’ away from base station up on a hill placed in an outdoor 3rd-party housing.

20 minutes of work.
basic knowledge of soldering needed

16 gauge electrical wire

dremel tool to poke a small hole in housing.

Thank you!!!
